Under Pressure? Swap That Gauge on Your Voyager
Is your Hayward Voyager filter not giving you the right pressure readings? A faulty gauge can compromise your system’s efficiency—but don’t worry, replacing it is quick and easy. In this video, we’ll show you how to remove and install a new pressure gauge so you can keep your pool system performing at its best.
Resource Details
Key Takeaways:
1. Learn how to safely shut off water flow before opening your filter system
2. Discover the proper technique for removing and installing a pressure gauge
3. Ensure your new gauge is leak-free with the right use of Teflon tape
Step-by-Step Process:
1. Turn off water flow using shut-off valves or Hayward black plugs in the skimmer and return lines
2. Open the air relief valve to release internal pressure
3. Loosen the black ring on the filter tank and drain the water
4. Remove the lid and unscrew the old pressure gauge from the adapter fitting
5. Apply Teflon tape to the new gauge and install it into the fitting
6. Reinsert the gauge into the lid and secure it with the wing nut
7. Reinstall the tank lid and black ring, then close the drain cap
