How to Replace a Hayward Full Return Assembly: Step-by-Step Guide
In this tutorial, The Great Escape walks you through the process of replacing a Hayward full return assembly. Whether you're dealing with wear and tear or upgrading your pool components, this guide will help you get the job done with ease.
Resource Details
Key Takeaways:
1. The return assembly replacement process requires lowering your water level and safely removing the old components.
2. Using the proper tools, like the seat removal tool, ensures you can remove tight fittings without damage.
3. Installing the new return assembly requires attention to gasket placement to avoid leaks and ensure a secure fit.
Step-by-Step Process:
1. Lower the Water Level: Start by lowering the water below the return jet to avoid water spillage during replacement.
2. Remove the Eyeball Assembly: Turn the lockring and eyeball counterclockwise to detach them.
3. Remove the Inner Fitting: If the fitting is tight, use the seat removal tool. Insert the key into the grooves and turn counterclockwise.
4. Remove the Old Return Assembly: Secure the return fitting from inside the pool, then turn the outside lock nut counterclockwise to loosen. Remove the old return and gaskets carefully.
5. Install the New Gaskets and Return Assembly: Place the first rubber gasket over the threads and push the return fitting through the cutout inside the pool. Install the second rubber gasket followed by the cork gasket on the outside of the pool and tighten the lock nut.
6. Install the Eyeball Assembly: Attach the inner fitting by turning clockwise. Insert the eyeball and loosely secure the lock ring, adjusting the eyeball’s position before fully tightening.
